Andersen Active Multipoint Lock, FWH68 Door - Stainless Steel

Andersen ACTIVE 3-Point Lock Mechanism – Frenchwood Hinged Patio Door

Stainless steel 3-point locking mechanism for Andersen Frenchwood Hinged Patio Doors built from 1988 to present. This mechanism features locking hooks at both the top and bottom of the door for enhanced security.

Product Specifications:

• Overall Length: 76-1/2 inch
• Faceplate Width: 7/8 inch
• Backset: 2 inch
• Handle Spacing (PZ): 4-3/16 inch
• Center of Deadbolt to Spring Latch: 1-3/8 inch
• Handle Height: 36-1/8 inch
• Bottom Hook Location: 31-1/8 inch (center of handle to center of hook)
• Top Hook Location: 35-1/2 inch (center of handle to center of hook)

Compatibility:

Fits Andersen 6 foot 8 inch tall Frenchwood Hinged Doors. Confirm your door panel height:

• 6'8" door panel = 76-7/16 inch
• 6'11" door panel = 79-3/8 inch
• 7'6" door panel = 86-7/16 inch
• 8'0" door panel = 93-1/2 inch

Important Note:

Check the 7-digit part number stamped on your faceplate. If you see both 2579771 and 2579774, verify whether your door includes shootbolts (locking bolts that extend into the floor and top frame). If your lock includes shootbolts, you need part 2579774.
